hey y'all!!

Been printing off these little card borders, printed two sets successfully at 0.08 layer height, then unloaded filament and reloaded it. Afterwards, prints have come out completely cooked. It's dry, I seriously doubt travel speed, any ideas?? I have never seen anything like this before. The left most one was printed before the right.

Cheers!

I get these weird artifacts that looks like some sort of extrusion issues. Could it be that i have tuned pressure advance incorrectly?

Printer: Voron 2 + DragonBurner (Orbiter 2.5 + Bambu X1 Hotend)
Slicer OrcaSlicer 2.4.2
Meterial: Sunlu ASA
Temperatures: 270/100
Speed: 160 mm/s
Retraction: 0.8 mm

I'm working on some arcade controllers. This is my first time using Choc V1 keyboard microswitches.

I downloaded a Choc v1 button from makerworld and duplicated the other guy's measurements for the part that sticks into the microswitch.

When I print his button... it works. When I print my button with the same dimensions, it does not work.

What am I doing wrong here because it's making me crazy!!

• Printer Model - Bambu P1s
• Slicer used (e.g. Cura, Prusa, etc.) - Bambu Studio
• Filament material and brand - Aliexpress PETG
• Nozzle and bed temperature - Nozzle - 255c / Bed - 75C
• Print Speed - 50 and then 105mm/s
• Retraction set - ?

​

Hi everyone, I need some help!

Originally, I was dealing with severe heat creep where the filament kept clogging right in the middle of the printhead.

To fix it, we replaced both the hotend cooling fan (axial) and the part cooling fan (blower), but the issue persisted—it would jam every 2 or 3 prints.

Eventually, we noticed the filament was sticking right past the PTFE tube, inside the metal heatbreak. So we decided to buy and install a brand-new hotend assembly.

After replacing it, the hotend heats up properly and melts filament smoothly when pushed manually through the nozzle. However, the actual problem now is that we have to push it manually: the extruder stepper motor won't engage at all, and the dual gears aren't spinning.

When we open the extruder casing / housing and turn the gears inside by hand, everything rotates freely, so there doesn't seem to be a mechanical jam. It just seems like the motor isn't receiving any power or step signals. I don't understand why this happened, since the motor was working fine before the hotend swap.

What could be causing this? AI narrowed it down to two main possibilities: either the extruder stepper motor died, or the toolhead breakout PCB (or its driver/cable) failed.

What do you guys think? Does that sound accurate, or is there something obvious we might be missing? Any advice is appreciated!

Bambu X1

Testing with ASB

This is the best result I've got from these supports. All sides are good except the support side. I'd appreciate any pointers!

Printed this model and have these weird bumps towards the back of the blade. Printed on my mostly stock Ender 3 V2 and the orientation is how it was printed in the first picture. Model link is this: https://makerworld.com/en/models/2576196-bonesaw#profileId-2840812

Edit: Slicer: CURA Filament : Creality PLA Print speed: 50 mm/s Bed temperature: 50 C Nozzle temperature: 200 C

They just appear when slicing and need to get rid of them.

I didn't have these issues before, they all just started to have these patterns. Any recommendations on what I should do?

Printer information:

Printer: Creality K1 Max rooted

Slicer: OrcaSlicer

Filament: SUNLU PLA dried

Nozzle: 0.4 mm stock

Nozzle temp: 220 °C (

Bed temp: 60 °C

Flow ratio: 0.98

Pressure advance: disabled in slicer

Max volumetric speed: 18 mm³/s

Lid/door: open

Layer height: 0.2 mm

Wall loops: 2

Top/bottom shells: 4 / 4 layers

Infill: 2% rectilinear

Speeds:

Outer wall 200 mm/s, inner wall 300 mm/s

Small perimeters 50%

Sparse infill 270, internal solid infill 250, top surface 200, gap infill 250 mm/s

First layer 60 mm/s, travel 600 mm/s

Seam: aligned, staggered inner seams on, scarf seam off

Qidi Max 4

Polymaker PC

First layer goes down great. Subsequent layers getting blobs. Temp dropped to 270. Max volumetric dropped from 12 to 8. PA is set where the PA tower was perfect. Flow is set to where my lines are what I set the width to be in orca. Cooling is off for PC. By the end of layer 2, my nozzle has some goop on it from these blobs catching.

I've cleaned the bed, dried the filament, lubricated and greased the machine, done flow rate calibration, flow dynamics calibration, bed leveling, XY belt tensioning, and ran the Bambu Lab calibration. (Unedited Bambu Studio profile "0.30mm Standard @ BBL H2C 0.6 nozzle")

Printer: Bambu Lab H2C
Slicer: Bambu Studio
Material: Bambu Lab PLA Basic

Temperatures: 220/55

Print Speeds: Initial layer: 50 mm/s, Initial layer infill: 105 mm/s, Outer wall: 200 mm/s, Inner wall: 300 mm/s, Small perimeters: 50%, Sparse infill: 350 mm/s, Internal solid infill: 250 mm/s, Vertical shell speed: 80%, Top surface: 200 mm/s, Bridge: 30 mm/s, Gap infill: 50 mm/s, Support: 150 mm/s, Support interface: 80 mm/s, Travel: 1000 mm/s.

Acceleration: Normal printing 8000 mm/s², Travel: 10000 mm/s², Initial layer travel: 6000 mm/s², Initial layer: 500 mm/s², Outer wall: 5000 mm/s², Inner wall: 0 mm/s², Top surface: 2000 mm/s², Sparse infill: 100%.

Overhang speed: 10: 0 mm/s, 25%: 50 mm/s, 50%: 30 mm/s, 75%: 10 mm/s, 100%: 10 mm/s.

Retraction Settings: Length: .4mm, Z Hop Type: Spiral, Wipe While Retracting: Enabled, Wipe Distance: 1mm.

Printer : Ender3 V3 Se

Filament: PLA Basic

Slicer: Orca

The layer lines at the same height as holes/slots looks different.

1st print is the baseline.

2nd print: At first troubleshooting, I thought this is ghosting/echoing. Hence I reduced speed and acceleration by 50%. 50ms, 500ms2. The improvement was negligible.

3rd print: Found one post on this sub with the same issue and it was identified that Layer time was the culprit. Hence I updated the cooling parameter to have maximum fan layer time as 16sec, which is the time it took to print the layers within hole section. The improvement was quite significant.

How do I fix the start and end layer difference which you see in print 3.

Help is appreciated

I've been having trouble with large prints that take up the whole build plate, warping and actually bending the build plate in my X2D. I've read that increasing bed and chamber temps can improve this. Anyone have recommendations for these temperatures?

Pla+, Kobra pro 2, ultiMaker Cura, 218°C, 90mm/s,

Things ai has suggested that I've done...

Reduce layer height (now .12)

Increase skin overlap percentage (now 27%)

Decrease retraction distance (now 1mm)

This is for an airplane so the wall count can not be higher than 1 and the infill can be no higher than 3%. I have tested with different tempatures & speed. I have made sure there is no blockage in the printer by pushing filament through manually and also performing cold pulls. The PLA+ is fresh out of the air sealed packaging. I have printed tons in the past this is the first time and it is the worst with the tree support.

Bambu p2s with bambulabs slicer, standard profile, but see the temp tower that didn't appear to show any issues. Pictured is PETG, but have tried ABS with the same results.

Appreciate any help, I'm not sure what to do next.

I have been printing on my x1 carbon with Asa for some time now and have never seen this happen. Any suggestions?

I’m not sure how to post all my printing settings. The settings are basically normal besides 5% infill

Centauri carbon
Filament - abs
Nozzle - 0.6mm 250-260
Bed - 105
Chamber - 50-60

Ive tried different inner outter orders, slowing down outter wall, slowing print speed and messed woth layer heights and widths

So was printing something from a friend and the Creality Yellow filament I’m using turned green? Any advice or thoughts? I’m using yellow, orange, and black on the main nozzle of my X2D. It’s interesting but not the color I want right now…..though might be nice to replicate for green parts down the line.

I am trying to print a rather large print and it is failing every single time. I have just switched filaments (elegoo PETG.) and this new filament will not print past the first layer. The filament is freshly dried for 10 hours, I adjusted the leveling, the flow rate, messed with retraction, cleaned the plate before and after many times, and slowed the speed down. it is still coming out in a huge blob and getting caught along the plate. the temperature ive been trying though it hasn't helped when being changed is 245 first layer then go down to 240 with a bed of 80 degrees. im tired of pulling these blobs out of the extruder so hopefully its a setting I'm missing... thanks for any and all help, I'm trying to make a cosplay for halloween :) the machine itself is a neptune plus 4

Reposted here for extra visibility
