Copied from the Mazda3 forum, as some of you aren't active on that website, and I wanted to increase visibility since some of yall were asking for it on my last post. Format will be weird, as I took my post on the Mazda3Revolution forum and pasted into Reddit, which doesn't allow inline photos.

Original post with replies: https://www.mazda3revolution.com/threads/19-26-knightsports-wing-review-caution-on-purchasing.260608/

---

Wanted to give a longer reference point for this wing, as discussions online are fairly lacking.

Originally, I chose this wing as it's the closest I could find to the Mazda Spirit Racing Mazda3 wing / some of the racing wings applied by Mazda to their own highly modified 3's. I really liked that wing, but couldn't find any other besides the knightsports wing.

(Photo #1)

(Photo #2)

Originally, when I received the wing, I installed it with a bit of difficulty. It doesn't come with any instructions (purchased from MikStore) so you have to do some carful measuring. I laid down some painters tape to mark on the original panel where I wanted to drill holes, which is a similar install to the OEM wing outside of the measuring.

It also did not come with any adhesive, or any replacements for the yellow clips that inevitably break when removing the black trunk exterior section that all wings mount to. You will need to order some or pick them up from a local mazda dealer for pennies on the dollar. You should grab 4 of them just in case something is funky during install, part number is KB8A-51-SJ3.

The wing itself isn't bad, it's not a perfect wing by any means however. Orange peel here and there, small dimples, meh paint overall. If I was going for a show car or was particular about detailing my car, I might sand down the whole thing, use some body filler, resand, and repaint the entire thing to be honest.

The real problem came in during the first time I closed the trunk.

(Photo #3)

If you notice, on the wing the original supports are VERY close together, and it functionally acts as a pair of "wings" when you close the trunk. Think of a bird, the inner supports are the chest and everything to the outside of the supports are the wings, and because of this they "flap". Everytime I closed the trunk, the furthest edge of the wing would gain momentum and slam into the upper portion of the rear panel, which was not a good experience since that is hard on the fiberglass wing and on the paint.

I had to make my own supports instead out of some 0.5" ABS. I couldn't cut plastic at the time, so I ordered 4 pieces of my CAD model from Send Cut Send for $30. If you cannot make these supports yourself, or do not want to pay a bodyshop to do it, I would not advise purchasing this wing. The initial wing is not structurally sound enough to handle it's own weight without these supports.

If I had to redo this over again, which I will at some point, I would have instead ordered a single sheet of 1.0" and trial and errored with a bandsaw until I got the curvature of the piece correct.​

I started by gluing my pieces together with some epoxy.

(Photo #4)

Once I had the general shape down, I proceeded to sand each side until I could attain the needed curvature for matching the internal supports shape. I had a belt sander I used for this. Once I had the general shape, I moved onto moving up in the grits until I felt comfortable priming them with some primer/filler, and then finally some black gloss.

(Photo #5)

Overall they came out okay, I don't have a perfect paint match on the gloss of the wing and have some orange peel here and there, but since this is primarily a structural piece that will be hidden by the wing itself, I am content.

I added some double sided adhesive to each side and prepped the wing surface with some rubbing alcohol to ensure the best bond possible.

(Photo #6)

(Photo #7)

(Photo #8)

(Photo #9)

(Photo #10)

What I would do / will do when I redo these supports in the future:

I would likely use the same abs supports, albeit slightly smaller, and commit to using a fiberglass and resin combo to permanently attach the supports to the wing. A couple of years later and the curvature of the original supports isn't perfect, putting a little stress on the overall wing and adhesive in particular which is starting to come up.

Instead, I would use fiberglass, resin, and filler to adhere the supports to a sanded portion of the wing, and then use some threaded inserts preinstalled on the bottom of the ABS supports to screw the wing into the upper portion of the hatchback, with some adhesive tape inbetween for cushioning and further waterproofing. This manner of fabrication would turn the wing into a single solid piece with 4 supports, instead of a single two support wing with additional supports on the side. I plan to eventually paint or vinyl wrap the car, so having a single unit is much preferred.

(Photo #11)

Overall aesthetic is one I really like. It's not as angular as the mazda spirit racing wing, which I think fits with the curvature of this gen of the 3 the best.
